Learn how to replace the primary storage drive assembly for the HP ENVY m6-w100 x360 Convertible PC. For other helpful videos go to or More support options for your HP device are available at
Note: The following video depicts a specific configuration of the notebook. The same removal and replacement procedures apply to all configurations of the notebook.
Before you begin: Remove the top cover.
Removal:
IMPORTANT: Ensure the battery cable is disconnected from its connector on the system board.
Using minimal force, lift the locking bar up on the primary storage drive ZIF connector and disconnect the primary storage drive ribbon cable from the system board.
CAUTION! Use care to prevent damaging the ZIF connector and ribbon cable.
Lift the primary storage drive assembly out of its cradle on the base enclosure and remove.
Place the primary storage drive assembly in a static-dissipative bag.
Replacement:
Remove the primary storage drive assembly from the static-dissipative bag.
Place the primary storage drive assembly into its cradle on the base enclosure.
Insert the primary storage drive ribbon cable into the primary storage drive ZIF connector on the system board and press the locking bar down to lock the cable into place.
CAUTION! Use care to prevent damaging the ZIF connector and ribbon cable.
Caution: Improperly installing or replacing parts could damage your HP device or void your warranty. Before replacing any parts, check your warranty.
